| Engine power, hp190 | Volume, m³6,5 | Wheel configuration / Drive formula4х2 |
| Chassis payload capacity, kg7000 |
ISUZU NQR90 L-H "Slingshot" Garbage Truck
Main Specifications:
- Engine: 5.2 L diesel (190 hp);
- Waste Bin Capacity: 6.5 m³;
- Maximum Load Capacity: 7,000 kg;
- Garbage truck with a rotating arm, capacity of 6.5 m³;
- Rotating arm cycle time: 60 sec;
- Maximum Bin Tilt Angle: 145°;
- 2023 Release.
Additional information:
Waste container:
1) Material: Q235 carbon steel;
2) Side plate thickness: 3 mm;
3) Bottom plate thickness: 4 mm.
Lift oil cylinder:
1) Working stroke: 1680 mm;
2) Opening diameter: 125 mm.
Rotary arm stroke:
1) 3740 mm in parallel unloading position;
2) 3890 mm in vertical working position.
| Engine power, hp | 190 |
|---|---|
| Volume, m³ | 6,5 |
| Wheel configuration / Drive formula | 4х2 |
| Chassis payload capacity, kg | 7000 |
-
