ISUZU 100P dump truck with crane, 4x2, 130 hp, 2 tons
Specification
| Payload capacity, kg2000 | Engine power, hp130 | Engine displacement, cm³2499 |
| Wheel configuration / Drive formula4х2 | Wheelbase, mm3360 | Crane unitХСМG LQS78А Grаb Сrаnе |
| Cargo compartment dimensions, mm2500 × 1850 × 550 | Crane lifting capacity, kg470 | Fuel typeDiesel engine |
Description
ISUZU 100P Dump Truck with Crane Manipulator, 4x2, 130 HP, 2 Tons
Technical Specifications
| Technical Specifications of Model 100P with Crane Manipulator | |
|---|---|
| General Information | |
| Model | 100P |
| Economic Class | Euro VI |
| Drive | 4x2 |
| Cabin and Comfort | |
| Type Cabins | Double row |
| Manual air conditioning | Yes |
| Central locking | Yes |
| Power windows | Yes |
| Trip computer display | Combination instrument |
| Engine and transmission | |
| Engine model | 4KV1-TSG60 |
| Displacement | 2.499 l |
| Power | 96 kW / 130 hp |
| Gearbox type | 5MT (5-speed manual) |
| Brake system | Pneumatic |
| Dimensions and weight | |
| Overall dimensions | 6480 × 1920 × 2650 mm |
| Interior dimensions | 2500 × 1850 × 550 mm |
| Wheelbase | 3360 mm |
| Total weight | 4495 kg |
| Unladen weight | 3700 kg |
| Load capacity (chassis) | 470 kg |
| Tire size | 7.00R16LT 8PR |
| KhSMG KSQZ32-2 Manipulator | |
| Maximum lifting capacity | 2000 kg |
| Maximum boom height | 6.5 m |
| Number of sections | 2 |
| Maximum lifting moment | 32 kN m |
| Maximum boom reach | 4.78 m |
| Slewing angle | 360° |
| Outriggers | 2800 mm |
| Maximum working pressure | 20 MPa |
| Recommended traffic | 20 l/min |
| Operation type | Lower control system |
| Tank capacity | 25 l |
| Turn weight of the manipulator | 670 kg |
| Superstructures | |
| Cargo box | Normal welding: side plate thickness 2 mm, bottom 4 mm |
Specifications ISUZU 100P dump truck with crane, 4x2, 130 hp, 2 tons
Equipment Specifications
| Payload capacity, kg | 2000 |
|---|---|
| Engine power, hp | 130 |
| Engine displacement, cm³ | 2499 |
| Wheel configuration / Drive formula | 4х2 |
| Wheelbase, mm | 3360 |
| Crane unit | ХСМG LQS78А Grаb Сrаnе |
| Cargo compartment dimensions, mm | 2500 × 1850 × 550 |
| Crane lifting capacity, kg | 470 |
| Fuel type | Diesel engine |
